Style C micro receptacle connector

With 1 screw

VP-VR-VT-VU - VT11 02A0S

VP-VR-VT-VU - VT11 02A0S

Haben Sie Fragen zu diesem Produkt?

Kontaktieren Sie unseren Steckverbinderspezialist

Schick mir ein individuelles Angebot

Download Datenblatt

Weitere Informationen über diese Marke:

Number Of Poles

2+G
3+G

Article Number	VT11 02A0S
Number Of Contacts	2+G
Protection Degree	IP65
Upper Temperature	+125 °C
Lower Temperature	-40 °C
Housing Material	PA66 30%GF
Housing Oil Resistance	Occasional contact
Contact Material	Nickel plated CuZn
Max. Wire Section	0,75 mm²
Voltage Vdc	1 to 250
Voltage Vac	1 to 250
Max. Currrent	6 A @40°C
Included Accessories	1 screw M2,5x8 1 gasket

Article Number	VT11 03A0S
Number Of Contacts	3+G
Protection Degree	IP65
Upper Temperature	+125 °C
Lower Temperature	-40 °C
Housing Material	PA66 30%GF
Housing Oil Resistance	Occasional contact
Contact Material	Nickel plated CuZn
Max. Wire Section	0,75 mm²
Voltage Vdc	1 to 250
Voltage Vac	1 to 250
Max. Currrent	6 A @40°C
Included Accessories	1 screw M2,5x8 1 gasket

Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
