SMT Insulation Displacement Connectors
Do you have any questions about this product?
More info on this brand:
Zierick
![Zierick](https://www.ac-solutions.be/themes/default/images/arrow.png)
Packaging
- Loose
- Small reeled
- Taped
Article Number | 1235 |
Extra Description | AWG 26-30 |
Material Thickness / Type | 0.020" (0.51mm) C26000 Brass |
Standard Finish | 100% Tin over Copper |
Current Rating Ul | AWG 30 solid & stranded 2.2 amperes AWG 28 solid & stranded 3.0 amperes AWG 26 solid & stranded 4.0 amperes |
Current Rating C-ul | AWG 30 solid & stranded 2.2 amperes AWG 28 solid & stranded 3.0 amperes AWG 26 solid & stranded 4.0 amperes |
Feeder System | Standard 12mm Tape Feeder |
Ul File Number | E361770 |
Wire Gauge Range | #26-30 AWG |
Wire Insertion Tool | WTPPS-1235-1: Pnuematic Production Tool |
Pieces Per Reel (loose Part No.) | NA |
Pieces Per Reel (taped Part No.) | / |
Pieces Per Reel (small Reel Part No.) | / |
Product sheet | Download product sheet |
Characteristics differ between variants of a connector
