Pin Crimp IP40 protection Power Socket
Avez-vous des questions sur ce produit?
Plus d’infos sur cette marque:
Techno
Number Of Poles
- 2
- 3
- 4
Article Number | THF.382.B2A |
Number Of Contacts | 2 |
Protection Degree | IP40 |
Upper Temperature | +125 °C |
Lower Temperature | -40 °C |
Rated Voltage | 400 |
Pollution Degree | 2 |
Rated Current | 10 A |
Contact Terminal | For universal cylindric pin ∅ 2 mm (not supplied). |
Terminals | Crimp |
Min-max Cable Diameter | 7,0 - 9,5 mm |
T Marking | T85 °C |
Impulse Withstand Category | II |
Impulse Withstand Voltage | 4 kV |
Tracking Index | PTI 175 |
Lock Nuts | PA66 GF UL94 V0 GWT 960°C black - grey RAL 7035 |
Connector Housing | PA66 UL94 V0/V2 GWT 850°C black - grey RAL 7035 |
Terminal Block Housing | PA66 GF UL94 V0 GWT 960°C black - grey RAL 7035 |
Grommets | TPE |
Contact Screw Terminals | Brass nickel plated OR Brass silver plated (THX.382.XXX.AG) |
Standards | EN61984:2001 |
Note | Every connector housing type can be equipped with male or female contacts. For reasons pertaining to safety, only female contacts may be used in the live part of the connector. |
Les propriétés diffèrent selon les variantes et sous-variantes
