Packaging
- Loose
- Reeled
- Taped
Article Number | 1266 |
Mating Terminal Size | 0.020" (0.51mm) to 0.025" (0.64mm) thick |
Material Thickness / Type | 0.008" (0.20mm) C51000 Phosphor Bronze |
Standard Finish | 100% Tin over Copper |
Current Rating Ul | 12 Amperes |
Current Rating C-ul | 12 Amperes |
Feeder System | Surf-Shooter SMT ™ Continuous Strip Feeder Standard 16mm Tape Feeder for PNs 1266-TV and 1266-TV-KT |
Ul File Number | E361770 |
Pieces Per Reel (loose Part No.) | NA |
Pieces Per Reel (reeled Part No.) | / |
Pieces Per Reel (taped Part No.) | / |
Product sheet | Download product sheet |
Eigenschappen verschillen tussen varianten en subvarianten
