Zierick
- General
| Article Number | 6120 |
| Packaging | Reeled |
| Mating Terminal Size | 0.250" x 0.032" (6.35mm x 0.81mm) Tin/Brass Male and Relays Dual/Multiple Matings |
| Material Thickness / Type | 0.025" (0.64mm) C26000 Brass |
| Standard Finish | 100% Tin over Copper |
| Current Rating | 25 Amperes |
| Applicator System | Model 9700, 9700 XY Bending Tool: ZPT-1120BT |
| Mating Type | Horizontal |
| Mounting Type | Outward or Inward Splay |
| Mounting Hole Diameter | 2 holes 0.052" ±0.003" (1.32mm ±0.076mm) on 0.400" ±0.005" (10.16mm ±0.127mm) centers |
| Resistance Rating | 20mOhm Max |
| Mating Entry | Horizontal |
| Temperature Rating | -65° to 85°C |
| Pieces Per Reel (reeled Part No.) | 3000 |
| Product sheet | Download product sheet |
