Packaging
- Reeled
Article Number | 6239 | 6240 |
Extra Description | With shoulder | With shoulder |
Pin Length (l) | 0.250" (6.35mm) | 0.375" (9.53mm) |
Material Thickness / Type | 0.012" (0.30mm) C26000 Brass | 0.012" (0.30mm) C26000 Brass |
Standard Finish | 100% Tin over Copper | 100% Tin over Copper |
Current Rating | 8 Amperes | 8 Amperes |
Feeder System | Surf-Shooter SMT ™ Continuous Strip Feeder | Surf-Shooter SMT ™ Continuous Strip Feeder |
Pieces Per Reel (reeled Part No.) | 9000 | 9000 |
Product sheet | Download product sheet | Download product sheet |
Eigenschappen verschillen tussen varianten en subvarianten
