JST
Number Of Poles
- 8
| Article Number | MJ-88H-RD315K | MJ-88R-RD315K | MJ-88U-SD315K-T |
| Number Of Contacts | 8 | 8 | 8 |
| Upper Temperature | +80 °C | +80 °C | +80 °C |
| Lower Temperature | -40 °C | -40 °C | -40 °C |
| General Description | Modular Jack Connectors (RJ45) | Modular Jack Connectors (RJ45) | Modular Jack Connectors (RJ45) |
| Connection Type | Interface Connection Connectors | Interface Connection Connectors | Interface Connection Connectors |
| Rated Current (ac/dc) | 1.3 A | 1.3 A | 1.3 A |
| Rated Voltage (ac/dc) | 250 V | 250 V | 250 V |
| Standard | RJ45 | RJ45 | RJ45 |
| Remark | Normal type (with shielding) | Normal type (with plastick hook) | Straight type (with shielding) |
Eigenschappen verschillen tussen varianten en subvarianten
Upper contact point
The MJ connector has an upper contact point design. With this construction, the contact points are free from dust even before the connector is mated with the modular plug.
Metal hook
The MJ connector has metal hooks, which provides click feeling when mounted on a PC board, and are soldered later. With these hooks, the connector can be securely mounted on the board, resistant against the external forces applied by the wires of the plug.
*Low profile type 8 circuits MJ connector with plastic hooks is
also available.
Shielding effect
By covering the whole connector, it provides a high quality shielding effect.
Grounding
By soldering the Shield Cover (the spring part), it provides secure grounding through the Hook to the PC board.
Standards
UL Recognized E174260
CSA Certified LR20812
Conforms to FCC Standards
RoHS Compliant
